AutoCAD Mechanical Toolset: Mechanical Drafting and Design in AutoCAD
The AutoCAD Mechanical toolset adds mechanical engineering tools to AutoCAD, including more than 700,000 standard parts and features. It's included with every AutoCAD subscription: buy AutoCAD from Hagerman and get ongoing support from our team, with live AutoCAD training available. With the Mechanical toolset, you can:
- Access a library of standards-based parts, tools, and custom content
- Customize properties of object types and create them on custom layers
- Automate tasks such as creating bills of materials (BOMs)
Have Questions?
Request Info
What is AutoCAD Mechanical?
AutoCAD Mechanical is a toolset for mechanical drafting and design that's included with Autodesk AutoCAD. It adds a library of more than 700,000 standard parts and features, plus tools that automate mechanical drawing tasks like layers, dimensions, hole charts, and bills of materials.
It's built for mechanical engineers, designers, and drafters who create 2D manufacturing drawings in AutoCAD, and it supports ISO, ANSI, DIN, JIS, BSI, CSN, and GB drafting standards. Autodesk reports productivity gains of up to 55% on common mechanical design tasks with the toolset.
AutoCAD Mechanical Features
Standard Parts Library
Insert from more than 700,000 standards-based parts and features, and save your own parts with the Content Manager.
Automatic Mechanical Layers
Commands create and manage mechanical layers for you, so drawings stay consistent.
Bills of Materials and Balloons
Automate bills of materials, parts lists, associative balloons, and part references.
Power Dimensioning
Dimension faster with power dimension commands and simplified settings.
Detailing Tools
Use hole charts, centerlines, hide-situation tools, and scale-area viewports to finish drawings faster.
Engineering Calculators
Run 2D calculations such as FEA, shaft calculations, and moment of inertia without leaving AutoCAD.
GD&T and Notes
Add pre-configured GD&T symbols from reusable libraries, and leader notes with formulas and templates.
Exceptional Training and Support
Hagerman Solutions Engineers prioritize customer success with every interaction. Hagerman Training classes are developed to give you the maximum value from your technology investment, and the Hagerman support desk delivers prompt, courteous assistance when you need help.
Course Catalog
View and register for upcoming Autodesk software training classes. All courses are virtual and taught live by Autodesk Certified Hagerman Solutions Engineers. Any course that is listed can be scheduled by request, and additional customized training courses are also available.
Hagerman Support Desk
Hagerman & Company Support provides critical technical assistance when you need help. Our certified Support Specialists act as an extension of your technical team and will help solve your issues quickly so you can get back to business.
