AutoCAD Architecture Toolset: Architectural Drafting in AutoCAD
The AutoCAD Architecture toolset adds architectural objects, like walls, doors, and windows, to AutoCAD. It's included with every AutoCAD subscription, so you get it when you buy AutoCAD from Hagerman, with ongoing support from our team and live AutoCAD training available. With the Architecture toolset you can:
- Access a library of more than 8,500 architectural components, including multilevel blocks
- Automatically generate floor plans, elevations, sections, and ceiling grids
- Quickly place walls, doors, and windows with real-world construction
Have Questions?
Request Info
What is AutoCAD Architecture?
AutoCAD Architecture is one of seven specialized toolsets included with Autodesk AutoCAD. It turns AutoCAD into an architectural drafting tool: instead of drawing lines that look like walls, you place wall, door, window, and space objects that know what they are. Plans, sections, elevations, and schedules then update from those objects.
It's built for architects, interior designers, and building designers who produce construction documents in AutoCAD's DWG format. Autodesk reports architectural drafting productivity gains of up to 61% with the toolset.
AutoCAD Architecture Features
Walls, Doors, and Windows
Place building objects that behave like real construction, so changes to a wall carry through to the openings in it.
Automatic Plans, Sections, and Elevations
Generate floor plans, elevations, sections, and ceiling grids from your model instead of drawing each one by hand.
Display System
Draw an object once; its appearance adapts automatically to plans, elevations, and different levels of detail.
Spaces and Zones
Organize spaces into zones for area reports and design schemes.
Layer Standards
Use predefined layer standards that create the right layers automatically as your add objects.
Renovation Mode
Show existing, demolished, and new construction in one drawing.
Detail Components
Browse and insert standard detail components from a filtered library.
